Toro Dingo TX 525 Wide Track Features:
use diagram above and match to the corresponding letter
CALL TO BUY OR FOR A DEMO 703 919 1379
We Can Ship The Toro Dingo 525 Wide Track To You Anywhere in the United States or Canada
E&S Equipment, LLC
6799 Kennedy Road Suite E
Warrenton VA 20187
(703) 919-1379
www.esequipmentllc.com
Toro Dingo TX 525 Wide Track Specifications
Toro Dingo 525 Wide Track
Engine
Kubota 25 horse power D902E3B diesel engine
Air Filter Cooling System Fuel Tank Oil Capacity Hydraulic System
PressureFlow Reservoir Capacity Auxiliary Horsepower Track
StandardTrack Drive
StandardTractionTwo-Stage, heavy duty, remote
Liquid Cooled
6 gallons
3.84 quarts
3000 psi
13.8 gpm auxillary, 6 gpm loader arm, 16.9 gpm traction for each traction pump
10.5 gallons
24 horsepower
Standard Endless Kevlar reinforced rubber, 96.6" x 9.5", single internal tooth drive
Sprocket drive, 10 road wheels per side, cast iron track guide
Dual hydrostatic pump
Dimensions
Track Width
(A) Wheelbase
(B) Ground Clearance
(C) Overall Length
Overall Width
(D) Overall Height
(E) Maximum Operating Height
(F) Hinge Pin Height
(G) Dump Height
(H) Dump Angle
(I) Reach
Ground Speed Tip Capacity
SAE J818 Rating 50% tip capacity
SAE J818 Rating 35% tip capacity
Weight with standard bucket
Weight with out standard bucket
Ground Pressure
9.5"
31.2"
4.6"
92" with bucket
70.7" without bucket 41"
46.1"
90.1"
65.8"
46.1"
38 degrees
21.8" fully raised
0-4.5 mph forward
0-2 mph reverse
1580 lbs
790 lbs
553 lbs
2127 lbs
2001 lbs
3.4 psi
No sales tax charged on 525 wide tracks shipped outside the state of Virginia
Financing programs available like $0 down and no payments for 120 days and 0 percent interest for 42 months. Other programs available too!
